Product code: ERV-DF-LIN-00026
A milking liner with a listed length of 148 mm, shown with a 108 mm matched-shell reference. The liner drawing lists diameters of 20 / 24 / 9.5 mm, and the shell drawing lists 41 / 23 mm. Select using the complete drawing dimensions.
Key features at a glance
- Liner length: 148 mm
- Liner drawing diameters: 20 / 24 / 9.5 mm
- Matched shell length: 108 mm
- Matched shell drawing diameters: 41 / 23 mm
Choose your configuration
| Model | Liner length | Liner drawing diameters | Shell reference length | Shell drawing diameters |
|---|---|---|---|---|
| ERV-DF-LIN-00025 | 175 mm | 24 / 19.5 mm | 147 mm | 44 / 27 mm |
| ERV-DF-LIN-00026 | 148 mm | 20 / 24 / 9.5 mm | 108 mm | 41 / 23 mm |
| ERV-DF-LIN-00027 | 158 mm | 20.5 / 22 / 12 mm | 129 mm | 48 / 19 mm |
Match the full liner and shell drawing
This 148 mm liner is listed with a 108 mm matched shell and 41 / 23 mm shell drawing diameters. Compare the complete dimensions rather than selecting only by the short liner length. The comparison identifies dimensions, not guaranteed interchangeability. Confirm material, operating requirements and whether a shell is included in the quotation.
Additional product details
Short silicone liner for goats
The factory identifies this short liner as a silicone configuration for goat and sheep milking. The reviewed catalogue length is 148 mm, with a 108 mm matched shell.
Check the current drawing
Request confirmation of the mouth and outlet measurements against the existing liner, as source drawings show small dimensional differences. Choose the complete profile and shell fit rather than ordering by length alone.
Specifications
| Liner length | 148 mm |
|---|---|
| Liner drawing diameters | 20 / 24 / 9.5 mm |
| Matched shell length | 108 mm |
| Matched shell drawing diameters | 41 / 23 mm |
| Material | Silicone |
Frequently asked questions
What are the liner and matched-shell dimensions?
- Liner length: 148 mm.
- Liner drawing diameters: 20 / 24 / 9.5 mm.
- Matched shell length: 108 mm.
- Matched shell drawing diameters: 41 / 23 mm. Diameter values correspond to the labels in the product drawing.
Is the shell included with the liner?
The shell image is provided as a dimensional reference. Confirm liner material, compatible shell, supplied components and quantity before ordering.
